Material	SUS304
Hole Shape	Square
Application	Filter, Construction Wire Mesh, Protecting Mesh, Screen, Decorative Mesh, Fence Mesh, Barbecue Wire Mesh, Window Curtain, Cages, Quarry Mesh
Type	Stainless Steel Mine Sieving Mesh
Material Type	Stainless Steel Wire
Weave Technique	Plain Weave
Model NO.	ZB-MSM-2
Wire Mesh Width	2m
Technique	Woven
Nickels	10%
Certification	ISO9001
Standard Length	30m
Wire Diameter	3.0mm-12.0mm
Width	0.5m-2.0m
Transport Package	Water Proof Paper, Pallets or as Required
Specification	ISO9001:2008
Origin	Hebei Province, China
HS Code	84219990
Production Capacity	50, 0000PCS/Year

Steel grades are listed in the table below:

Carbon Steel Grades
No.	Steel Grade	Chemical Composition (%)
		C	Si	Mn
1	#45	0.42-0.50	0.17-0.37	0.50-0.80
2	#50	0.47-0.55
3	#55	0.52-0.60
4	#60	0.57-0.65
5	#65	0.62-0.70
6	#70	0.67-0.75
7	65Mn	0.62-0.70		0.90-1.20
8	72A	0.70-0.75	0.15-0.35	0.30-0.60
Note:  Steel grades #45, #50 and #55 are medium-carbon steel. Steel grades #60, #65, #70, 65Mn and 72A are high carbon steel.

4. How Many Side Edge Types are Available from Tec-Sieve? As a rule, in terms of quarries or mining industry, woven wire space cloth screens are provided with side edge hooks or edge treatments for tensioning purposes.  Unless otherwise specified, hooked side edges for heavy and medium duty space cloths are about 30mm long (from the inside of the bend to the end of the hook) and at a 45-60º degree angle from the face of the space cloth. Four side edge types are available from Tec-Sieve.Vibrating Screen Mesh/Crimped Wire Mesh for Mine Sieving 1. What is Woven Wire Space Cloth? Woven wire space cloth is square opening woven screen cloth/steel fabric, which is designated by the width of the space or clear opening between the inside edges of two parallel wires or strands.  2.What is Woven Wire Space Cloth Used for? Woven wire space cloth falls into a group of specifications which are used for screening, sieving, sizing and separating of solids, typically specified by the actual clear opening size rather than by the mesh count.  Tec-Sieve woven wire space cloth is pre-crimped woven wire cloth which is designated by the clear opening size between wires.  3. Which Steel Grades Are Usually Used to Manufacture Tec-Sieve Woven Wire Space Cloth?  In case of quarrying and mining applications, Tec-Sieve usually uses M&H carbon steel to weave space cloth.
